Color CMOS Cameras

SK - SKDCE - STC

Color CMOS Cameras
In stock
SKU
SK - SKDCE - STC
OptoSigma offers both analog and digital camera modules for use with our microscope systems.  The analog camera is best suited for remote observation owing to the longer cable lengths between the camera and a monitor. The connection interface is BNC.  With the digital cameras, it is easy to process and save images by installing the viewer software that comes with the camera on a PC. It is available in pixel formats from 2 to 20 MP, according to the required resolution.  The connection interface is USB 3.0.
custom product
Customize product
Filters
Enabled filters :
Remove all filters
Name Mounting Thread Delivery Price Add to cart
i
20.0 Mega Pixel Color Camera, C-Mount, USB3.0 Super Speed Interface
STC-MCS2041U3V
1/4-20UNC
6-12 weeks
$1,290.00
Spectral Region Color
Interface USB3.0 Super Speed
Sensor Size 1in. (20.5 Mega-pixels)
Chip Size (HxV) 13.1x8.8mm
Pixels (HxV) 5472x3648
Pixel-Cell Size (HxV) 2.4x2.4um
Frame Rate 18.5 FPS (at 8 Bit Output)
Shutter Type Global
Lens Mount C-Mount
Accessory Viewer Software (USB camera driver Image loading software)
Operating System (OS) Windows 32bit/64bit
External Dimensions<br>(excluding connector/protrusion) 35x35x41.5mm
i
Camera One Third Inch C Mount with BNC Analog Interface
SK-N63SCJ-C
1/4-20UNC
2 weeks
-
Interface BNC
Imaging Device 1/3 (0.4 Mega-pixels)
Chip Size (HxV) 4.9×3.7mm
Pixels (HxV) 768×494
Cell Size (HxV) 7.4×6.3μm
Frame Rate 30ps
Lens Mount C mount
Accessory AC adapter
Operating System (OS) -
External Dimensions<br>(excluding connector/protrusion) 36×36×42mm
i
4.0 Mega Pixel Near-IR Camera, C-Mount, USB3.0 Super Speed Interface
STC-MBCM401U3V-NIR
M4
6-12 weeks
$1,650.00
Spectral Region Near IR
Interface USB3.0 Super Speed
Sensor Size 1" (4.2 Mega-pixels)
Chip Size (HxV) 11.3x11.3mm
Pixels (HxV) 2048x2048
Pixel-Cell Size (HxV) 5.5x5.5um
Frame Rate 89 FPS (@ 8 Bit Output)
Shutter Type Global
Lens Mount C-Mount
Accessory Viewer Software (USB camera driver Image loading software)
Operating System (OS) Windows 32bit/64bit
External Dimensions<br>(excluding connector/protrusion) 28x28x40mm
i
3.2 Mega Pixel Color Camera, C-Mount, USB3.0 Super Speed Interface
STC-MCS312U3V
M4
6-12 weeks
$1,110.00
Spectral Region Color
Interface USB3.0 Super Speed
Sensor Size 1/1.8in. (3.2 Mega-pixels)
Chip Size (HxV) 7.1x5.3mm
Pixels (HxV) 2048x1536
Pixel-Cell Size (HxV) 3.5x3.5um
Frame Rate 56 FPS (at 8 Bit Output)
Shutter Type Global
Lens Mount C-Mount
Accessory Viewer Software (USB camera driver Image loading software)
Operating System (OS) Windows 32bit/64bit
External Dimensions<br>(excluding connector/protrusion) 28x28x40mm
i
4.0 Mega Pixel Color Camera, C-Mount, USB3.0 Super Speed Interface
STC-MCCM401U3V
M4
6-12 weeks
$1,295.00
Spectral Region Color
Interface USB3.0 Super Speed
Sensor Size 1in. (4.2 Mega-pixels)
Chip Size (HxV) 11.3x11.3mm
Pixels (HxV) 2048x2048
Pixel-Cell Size (HxV) 5.5x5.5um
Frame Rate 89 FPS (at 8 Bit Output)
Shutter Type Global
Lens Mount C-Mount
Accessory Viewer Software (USB camera driver Image loading software)
Operating System (OS) Windows 32bit/64bit
External Dimensions<br>(excluding connector/protrusion) 28x28x40mm
i
5 Mega Pixel Color Camera C Mount, USB 3 Interface
STC-MCA5MUSB3-E
M4
2 weeks
$892.50
Interface USB3.0 Super Speed
Imaging Device 1/2.5 (5 Mega-pixels)
Chip Size (HxV) 5.7×4.28mm
Pixels (HxV) 2592×1944
Cell Size (HxV) 2.2×2.2μm
Frame Rate 14ps
Lens Mount C mount
Accessory Viewer Software (USB camera driver Image loading software)
C mount conversion adapter
Operating System (OS) Windows®XP、Vista、7、8.1、10(32bit/64bit)
External Dimensions<br>(excluding connector/protrusion) 28×28×33.8mm
i
9.0 Mega Pixel Color Camera, C-Mount, USB3.0 Super Speed Interface
STC-MCS881U3V
1/4-20UNC
6-12 weeks
$2,220.00
Spectral Region Color
Interface USB3.0 Super Speed
Sensor Size 1" (9.0 Mega-pixels)
Chip Size (HxV) 14.1x7.5mm
Pixels (HxV) 4096x2160
Pixel-Cell Size (HxV) 3.5x3.5um
Frame Rate 32.5 FPS (@ 8 Bit Output)
Shutter Type Global
Lens Mount C-Mount
Accessory Viewer Software (USB camera driver Image loading software)
Operating System (OS) Windows32bit/64bit
External Dimensions<br>(excluding connector/protrusion) 35x35x41.5mm
i
2.3 Mega Pixel Color Camera, C-Mount, USB3.0 Super Speed Interface
STC-MCS231U3V
M4
6-12 weeks
$810.00
Spectral Region Color
Interface USB3.0 Super Speed
Sensor Size 1/1.2in. (2.3 Mega-pixels)
Chip Size (HxV) 11.3x7.0mm
Pixels (HxV) 1920x1200
Pixel-Cell Size (HxV) 5.86x5.86um
Frame Rate 41.6 FPS (at 8 Bit Output)
Shutter Type Global
Lens Mount C-Mount
Accessory Viewer Software (USB camera driver Image loading software)
Operating System (OS) Windows 32bit/64bit
External Dimensions<br>(excluding connector/protrusion) 28x28x40mm
i
12.0 Mega Pixel Color Camera, C-Mount, USB3.0 Super Speed Interface
STC-MCS122BU3V
1/4-20UNC
6-12 weeks
$2,700.00
Spectral Region Color
Interface USB3.0 Super Speed
Sensor Size 1.1in. (12.4 Mega-pixels)
Chip Size (HxV) 14.1x10.4mm
Pixels (HxV) 4096x3000
Pixel-Cell Size (HxV) 3.5x3.5um
Frame Rate 23.5 FPS (at 8 Bit Output)
Shutter Type Global
Lens Mount C-Mount
Accessory Viewer Software (USB camera driver Image loading software)
Operating System (OS) Windows 32bit/64bit
External Dimensions<br>(excluding connector/protrusion) 35x35x41.5mm
i
5 Mega Pixel Color Camera C Mount, USB 3 Interface with CE marking
STC-MCA5MUSB3
M4
2 weeks
-
Interface USB3.0 Super Speed
Imaging Device 1/2.5 (5 Mega-pixels)
Chip Size (HxV) 5.7×4.28mm
Pixels (HxV) 2592×1944
Cell Size (HxV) 2.2×2.2μm
Frame Rate 14ps
Lens Mount CS mount
Accessory Viewer Software (USB camera driver Image loading software)
C mount conversion adapter
Operating System (OS) Windows®XP、Vista、7、8.1、10(32bit/64bit)
External Dimensions<br>(excluding connector/protrusion) 28×28×33.8mm
i
5.0 Mega Pixel Color Camera, C-Mount, USB3.0 Super Speed Interface
STC-MCS500U3V
M4
6-12 weeks
$1,210.00
Spectral Region Color
Interface USB3.0 Super Speed
Sensor Size 2/3in. (5.0 Mega-pixels)
Chip Size (HxV) 8.4x7.1mm
Pixels (HxV) 2448x2048
Pixel-Cell Size (HxV) 3.5x3.5um
Frame Rate 35.8 FPS (at 8 Bit Output)
Shutter Type Global
Lens Mount C-Mount
Accessory Viewer Software (USB camera driver Image loading software)
Operating System (OS) Windows 32bit/64bit
External Dimensions<br>(excluding connector/protrusion) 28x28x40mm
