Cylindrical Plano-convex Lens (BK7) 20×70mm 30mm Focal Length Uncoated
CLB-2070-30P
Cylindrical plano convex lens has a convex curvature in the vertical direction and has no curvature in the horizontal direction. They are often used to condense a laser beam into a thin line.
◦Plano Convex Cylindrical lenses are available in BK7 for from visible range to infrared wavelength range.
◦BK7 lenses are also available with three types of anti-reflection coatings, visible wavelength range, in the near-infrared range and in the infrared range.
◦Cylindrical lenses are often used in an optical system to change the shape and aspect ratio of the illumination light beam.
◦BK7 lenses are also available with three types of anti-reflection coatings, visible wavelength range, in the near-infrared range and in the infrared range.
◦Cylindrical lenses are often used in an optical system to change the shape and aspect ratio of the illumination light beam.
| Name | Cylindrical Plano-convex Lens (BK7) 20×70mm 30mm Focal Length Uncoated |
|---|---|
| Weight | 0.0220kgs |
| Standard Coatings Available | Yes |
| Guide |
|
| Remark | - |
| Attention |
|
| A x B | 20mm x 70mm |
| Focal length | 30mm |
| Material | BK7 |
| Design Wavelength | 546.1nm |
| Refractive index n<sub>e</sub> | 1.519 |
| Coating | Uncoated |
| Clear aperture | Circle or ellipse inscribed in a rectangular of 90% of the dimension |
| Surface Quality (Scratch-Dig) | 20-10 |
| Wavelength range of Antireflection Coating | Uncoated |
| A×B | 20×70mm |
| Focal length f | 30mm |
| Edge thickness te | 2.4mm |
| Center thickness tc | 6mm |
| Back focal length fb | 26.1mm |
| Radius of curvature r | 15.57mm |
