Notch Filter

Notch Filter

SKU : NF

In stock
SKU
NF
Notch filter is a filter that cuts only a specific wavelength. It is not the same as the interference filter which transmits only a specific wavelength. By using a dielectric multilayer coating the product has very high stability and has environmental resistance.
Name Material Delivery Price Add to cart
Notch Filter 25mm Diameter BK7 633nm
NF-25C05-47-633
BK7
3-6 weeks
-
Notch Filter 25mm Diameter Synthetic Fused Silica 355nm
NF-25C05-27-355
Synthetic fused silica
3-6 weeks
-
Notch Filter 25mm Diameter BK7 1064nm
NF-25C05-80-1064
BK7
5-10 days
-
Notch Filter 25mm Diameter BK7 532nm
NF-25C05-40-532
BK7
5-10 days
-

You must be logged in to ask questions

◦Four types are available 355nm, 532nm, 633nm and 1064nm.
◦Because it is a dielectric multilayer coating, there is almost no absorption by the coating.
◦By using in combination with other filters, it can also be used as filter sets for Bio-Imaging.
