Standard Rotation Stages

KSP

In stock

SKU

KSP

Low profile rotation stages offer coarse rotation adjustment of 360° and fine adjustment (with either a micrometer head or fine-pitch screw).
Directly rotate the stage upper plate for coarse adjustment, then clamp the clutch screw and use micrometer head or fine-pitch screw (±5°) for fine adjustment.

Add to Wish List

Customize product

Name Stage Size Rotation Range Load Capacity Mounting Thread Delivery Price Add to cart

25mm Diameter, Brass, Lapped-Surface Bearing Rotation Stage, 360 Deg Manual Rotation, +/-5 Deg Fine Adjustment, Fine Screw Drive, M2 Threads
KSP-256

φ25mm

Coarse:360°　Fine:±5°

29.4N (3.0kg)

2 weeks

$263.00

Stage Size	φ25mm
Rotation Range	Coarse:360° Fine:±5°
Scale Readable Resolution	2°
Micrometer Readable Resolution	-
Guide Method	Lapping method
Primary Material	Brass
Finish	Super black chrome
Load Capacity	29.4N(3.0kgf)
Max. Moment Capacity	0.15N･m
Moment Stiffness	6.1″/N･cm
Parallelism	20μm
Eccentricity	20μm
Wobble	15μm

40mm Diameter, Brass, Lapped-Surface Bearing Rotation Stage, 360 Deg Manual Rotation, +/-5 Deg Fine Adjustment, Micrometer Drive, 6-32 Threads
KSP-406MUU

φ40mm

Coarse:360°　Fine:±5°

49N (5.0kg)

6-32UNC

2 weeks

$290.00

Stage Size	φ40mm
Rotation Range	Coarse:360° Fine:±5°
Scale Readable Resolution	2°
Micrometer Readable Resolution	about 1′24.2″
Guide Method	Lapping method
Primary Material	Brass
Finish	Super black chrome
Load Capacity	49N(5.0kgf)
Max. Moment Capacity	0.3N･m
Moment Stiffness	1.5″/N･cm
Parallelism	20μm
Eccentricity	20μm
Wobble	20μm

40mm Diameter, Brass, Lapped-Surface Bearing Rotation Stage, 360 Deg Manual Rotation, +/-5 Deg Fine Adjustment, Hex Screw Drive, 6-32 Threads
KSP-406FPUU

φ40mm

Coarse:360°　Fine:±5°

49N (5.0kg)

6-32UNC

6-12 weeks

$250.00

Stage Size	φ40mm
Rotation Range	Coarse:360° Fine:±5°
Scale Readable Resolution	2°
Micrometer Readable Resolution	-
Guide Method	Lapping method
Primary Material	Brass
Finish	Super black chrome
Load Capacity	49N(5.0kgf)
Max. Moment Capacity	0.3N･m
Moment Stiffness	1.5″/N･cm
Parallelism	20μm
Eccentricity	20μm
Wobble	20μm

65mm Diameter, Brass, Lapped-Surface Bearing Rotation Stage, 360 Deg Manual Rotation, +/-5 Deg Fine Adjustment, Micrometer Drive, M6 Threads
KSP-656M-M6

φ65mm

Coarse:360°　Fine:±5°

68.6N (7.0kg)

in stock

$395.00

Stage Size	φ65mm
Rotation Range	Coarse:360° Fine:±5°
Scale Readable Resolution	1°
Micrometer Readable Resolution	about 52.2″
Guide Method	Lapping method
Primary Material	Brass
Finish	Super black chrome
Load Capacity	68.6N(7.0kgf)
Max. Moment Capacity	0.75N･m
Moment Stiffness	0.4″/N･cm
Parallelism	20μm
Eccentricity	20μm
Wobble	20μm

60mm Diameter, Brass, Lapped-Surface Bearing Rotation Stage, 360 Deg Manual Rotation, +/-5 Deg Fine Adjustment, Hex Screw Drive, M4 Threads
KSP-606FP

φ60mm

Coarse:360°　Fine:±5°

68.6N (7.0kg)

2 weeks

$329.00

Stage Size	φ60mm
Rotation Range	Coarse:360° Fine:±5°
Scale Readable Resolution	1°
Micrometer Readable Resolution	-
Guide Method	Lapping method
Primary Material	Brass
Finish	Super black chrome
Load Capacity	68.6N(7.0kgf)
Max. Moment Capacity	0.75N･m
Moment Stiffness	1.0″/N･cm
Parallelism	20μm
Eccentricity	20μm
Wobble	20μm

65mm Diameter, Brass, Lapped-Surface Bearing Rotation Stage, 360 Deg Manual Rotation, +/-5 Deg Fine Adjustment, Hex Screw Drive, 1/4-20 Threads
KSP-656FPUU

φ65mm

Coarse:360°　Fine:±5°

68.6N (7.0kg)

1/4-20UNC

2 weeks

$355.00

Stage Size	φ65mm
Rotation Range	Coarse:360° Fine:±5°
Scale Readable Resolution	1°
Micrometer Readable Resolution	-
Guide Method	Lapping method
Primary Material	Brass
Finish	Super black chrome
Load Capacity	68.6N(7.0kgf)
Max. Moment Capacity	0.75N･m
Moment Stiffness	0.4″/N･cm
Parallelism	20μm
Eccentricity	20μm
Wobble	20μm

40mm Diameter, Brass, Lapped-Surface Bearing Rotation Stage, 360 Deg Manual Rotation, +/-5 Deg Fine Adjustment, Micrometer Drive, M3 Threads
KSP-406M

φ40mm

Coarse:360°　Fine:±5°

49N (5.0kg)

6-12 weeks

$290.00

Stage Size	φ40mm
Rotation Range	Coarse:360° Fine:±5°
Scale Readable Resolution	2°
Micrometer Readable Resolution	about 1′24.2″
Guide Method	Lapping method
Primary Material	Brass
Finish	Super black chrome
Load Capacity	49N(5.0kgf)
Max. Moment Capacity	0.3N･m
Moment Stiffness	1.5″/N･cm
Parallelism	20μm
Eccentricity	20μm
Wobble	20μm

40mm Diameter, Brass, Lapped-Surface Bearing Rotation Stage, 360 Deg Manual Rotation, +/-5 Deg Fine Adjustment, Hex Screw Drive, M3 Threads
KSP-406FP

φ40mm

Coarse:360°　Fine:±5°

49N (5.0kg)

6-12 weeks

$250.00

Stage Size	φ40mm
Rotation Range	Coarse:360° Fine:±5°
Scale Readable Resolution	2°
Micrometer Readable Resolution	-
Guide Method	Lapping method
Primary Material	Brass
Finish	Super black chrome
Load Capacity	49N(5.0kgf)
Max. Moment Capacity	0.3N･m
Moment Stiffness	1.5″/N･cm
Parallelism	20μm
Eccentricity	20μm
Wobble	20μm

60mm Diameter, Brass, Lapped-Surface Bearing Rotation Stage, 360 Deg Manual Rotation, +/-5 Deg Fine Adjustment, Micrometer Drive, M4 Threads
KSP-606M

φ60mm

Coarse:360°　Fine:±5°

68.6N (7.0kg)

6-12 weeks

$369.00

Stage Size	φ60mm
Rotation Range	Coarse:360° Fine:±5°
Scale Readable Resolution	1°
Micrometer Readable Resolution	about 55.8″
Guide Method	Lapping method
Primary Material	Brass
Finish	Super black chrome
Load Capacity	68.6N(7.0kgf)
Max. Moment Capacity	0.75N･m
Moment Stiffness	0.4″/N･cm
Parallelism	20μm
Eccentricity	20μm
Wobble	20μm

65mm Diameter, Brass, Lapped-Surface Bearing Rotation Stage, 360 Deg Manual Rotation, +/-5 Deg Fine Adjustment, Micrometer Drive, 1/4-20 Threads
KSP-656MUU

φ65mm

Coarse:360°　Fine:±5°

68.6N (7.0kg)

1/4-20UNC

2 weeks

$395.00

Stage Size	φ65mm
Rotation Range	Coarse:360° Fine:±5°
Scale Readable Resolution	1°
Micrometer Readable Resolution	about 52.2″
Guide Method	Lapping method
Primary Material	Brass
Finish	Super black chrome
Load Capacity	68.6N(7.0kgf)
Max. Moment Capacity	0.75N･m
Moment Stiffness	0.4″/N･cm
Parallelism	20μm
Eccentricity	20μm
Wobble	20μm

60mm Diameter, Brass, Lapped-Surface Bearing Rotation Stage, 360 Deg Manual Rotation, +/-5 Deg Fine Adjustment, Hex Screw Drive, M4 Threads
KSP-606FPR

φ60mm

Coarse:360°　Fine:±5°

68.6N (7.0kg)

2 weeks

$329.00

Stage Size	φ60mm
Rotation Range	Coarse:360° Fine:±5°
Scale Readable Resolution	1°
Micrometer Readable Resolution	-
Guide Method	Lapping method
Primary Material	Brass
Finish	Super black chrome
Load Capacity	68.6N(7.0kgf)
Max. Moment Capacity	0.75N･m
Moment Stiffness	1.0″/N･cm
Parallelism	20μm
Eccentricity	20μm
Wobble	20μm

60mm Diameter, Brass, Lapped-Surface Bearing Rotation Stage, 360 Deg Manual Rotation, +/-5 Deg Fine Adjustment, Hex Screw Drive, M4 Threads
KSP-786FP

φ60mm

Coarse:360°　Fine:±5°

49N (5.0kg)

2 weeks

$290.00

Stage Size	φ60mm
Rotation Range	Coarse:360° Fine:±5°
Scale Readable Resolution	5′
Micrometer Readable Resolution	-
Guide Method	Lapping method
Primary Material	Aluminum
Finish	Black anodized
Load Capacity	49N(5.0kgf)
Max. Moment Capacity	1.3N･m
Moment Stiffness	1.5″/N･cm
Parallelism	50μm
Eccentricity	20μm
Wobble	20μm

90mm Diameter, Brass, Crossed-Roller Bearing Rotation Stage, 360 Deg Manual Rotation, +/-5 Deg Fine Adjustment, Hex Screw Drive, M4 Threads
KSPB-906FP

φ90mm

Coarse:360°　Fine:±5°

147N (15.0kg)

2 weeks

$460.00

Stage Size	φ90mm
Rotation Range	Coarse:360° Fine:±5°
Scale Readable Resolution	5′
Micrometer Readable Resolution	-
Guide Method	Crossed roller
Primary Material	Brass
Finish	Super black chrome
Load Capacity	147N(15.0kgf)
Max. Moment Capacity	5.0N･m
Moment Stiffness	0.2″/N･cm
Parallelism	50μm
Eccentricity	20μm
Wobble	20μm

40mm Diameter, Brass, Lapped-Surface Bearing Rotation Stage, 360 Deg Manual Rotation, +/-5 Deg Fine Adjustment, Micrometer Drive, M3 Threads
KSP-406MR

φ40mm

Coarse:360°　Fine:±5°

49N (5.0kg)

2 weeks

$290.00

Stage Size	φ40mm
Rotation Range	Coarse:360° Fine:±5°
Scale Readable Resolution	2°
Micrometer Readable Resolution	about 1′24.2″
Guide Method	Lapping method
Primary Material	Brass
Finish	Super black chrome
Load Capacity	49N(5.0kgf)
Max. Moment Capacity	0.3N･m
Moment Stiffness	1.5″/N･cm
Parallelism	20μm
Eccentricity	20μm
Wobble	20μm

40mm Diameter, Brass, Lapped-Surface Bearing Rotation Stage, 360 Deg Manual Rotation, +/-5 Deg Fine Adjustment, Hex Screw Drive, M3 Threads
KSP-406FPR

φ40mm

Coarse:360°　Fine:±5°

49N (5.0kg)

2 weeks

$250.00

Stage Size	φ40mm
Rotation Range	Coarse:360° Fine:±5°
Scale Readable Resolution	2°
Micrometer Readable Resolution	-
Guide Method	Lapping method
Primary Material	Brass
Finish	Super black chrome
Load Capacity	49N(5.0kgf)
Max. Moment Capacity	0.3N･m
Moment Stiffness	1.5″/N･cm
Parallelism	20μm
Eccentricity	20μm
Wobble	20μm

60mm Diameter, Brass, Lapped-Surface Bearing Rotation Stage, 360 Deg Manual Rotation, +/-5 Deg Fine Adjustment, Micrometer Drive, M4 Threads
KSP-606MR

φ60mm

Coarse:360°　Fine:±5°

68.6N (7.0kg)

2 weeks

$369.00

Stage Size	φ60mm
Rotation Range	Coarse:360° Fine:±5°
Scale Readable Resolution	1°
Micrometer Readable Resolution	about 55.8″
Guide Method	Lapping method
Primary Material	Brass
Finish	Super black chrome
Load Capacity	68.6N(7.0kgf)
Max. Moment Capacity	0.75N･m
Moment Stiffness	1.0″/N･cm
Parallelism	20μm
Eccentricity	20μm
Wobble	20μm

60mm Diameter, Brass, Lapped-Surface Bearing Rotation Stage, 360 Deg Manual Rotation, +/-5 Deg Fine Adjustment, Vernier Scale, Micrometer Drive, M4 Threads
KSP-786M

φ60mm

Coarse:360°　Fine:±5°

49N (5.0kg)

2 weeks

$329.00

Stage Size	φ60mm
Rotation Range	Coarse:360° Fine:±5°
Scale Readable Resolution	5′
Micrometer Readable Resolution	about 51.6″
Guide Method	Lapping method
Primary Material	Aluminum
Finish	Black anodized
Load Capacity	49N(5.0kgf)
Max. Moment Capacity	1.3N･m
Moment Stiffness	1.5″/N･cm
Parallelism	50μm
Eccentricity	20μm
Wobble	20μm

65mm Diameter, Brass, Lapped-Surface Bearing Rotation Stage, 360 Deg Manual Rotation, +/-5 Deg Fine Adjustment, Hex Screw Drive, M6 Threads
KSP-656FP-M6

φ65mm

Coarse:360°　Fine:±5°

68.6N (7.0kg)

2 weeks

$355.00

Stage Size	φ65mm
Rotation Range	Coarse:360° Fine:±5°
Scale Readable Resolution	1°
Micrometer Readable Resolution	-
Guide Method	Lapping method
Primary Material	Brass
Finish	Super black chrome
Load Capacity	68.6N(7.0kgf)
Max. Moment Capacity	0.75N･m
Moment Stiffness	0.4″/N･cm
Parallelism	20μm
Eccentricity	20μm
Wobble	20μm

You must be logged in to ask questions

The main body of these stages is made of brass for high stiffness and incorporate plain bearings for high performance and small size.
The through hole at the center of the stage can be used as a transmission hole.
A scale around the circumference provides an indication of the angle.
