Ultra-Thin DC Motor Actuators

SGDC

Ultra-Thin DC Motor Actuators
In stock
SKU
SGDC

Starting at $244.80

The SGCD low-cost DC motor actuators are open-loop and intended for simple automated or remote movement of linear stages or other precision positioners. SGDC Actuators are equipped with a thin-diameter 6V DC motor which provides exceptionally high-thrust loads. The actual diameter is only 10mm. All SGDC actuators have a non-rotating spindle which reduces contact-point friction and improves repeatability and durability. Using an SRC-series controller, incremental resolutions under 100nm are achievable. Also, at the slowest speeds, this actuator is capable moving loads exceeding 20 kgf. The standard 9.5mm threaded mounting shank allows these actuators to be mounted on most OptoSigma translation stages.
custom product
Customize product
Filters
Enabled filters :
Remove all filters
Name Travel Load Capacity Delivery Price Add to cart
i
31.5mm Travel, DC Motor Actuator, 9.5mm Threaded Shank, Non-rotating Spindle, 3kg Load
SGDC10-25
31.5mm 29.4N (3.0kg)
in stock
$285.60
Travel 31.5mm
Travel Speed 1.0mm/sec at Max Load
Thrust Force 29.5N(3.0kgf) at Max Speed. Please note that the maximum thrust force can be over 20kgf a low speeds.
Lead of Screw 0.5mm Per Thread
Typical Movement Sensitivity <100nm
Backlash <30um
Actuator Tip Flat Tip, Non Rotating
Motor Type 6V DC
Operation Enviornment 5-40 C, 20-80% Humidity (No condensation)
Length of Attached Cable 500mm (19.7 in.)
Mounting Interface Standard M9.5x0.5 Thread
Spindle Diameter 5mm (The spindle is non rotating)
Compatible Controllers SRC-101 and SRC-201
Compatible Extension cables MDC-4-2, MDC-4-3, MDC-4-5
i
17.5mm Travel, DC Motor Actuator, 9.5mm Threaded Shank, Non-rotating Spindle, 3kg Load
SGDC10-13
17.5mm 29.4N (3.0kg)
in stock
$244.80
Travel 17.5mm
Travel Speed 1.0mm/sec at Max Load
Thrust Force 29.5N(3.0kgf) at Max Speed. Please note that the maximum thrust force can be over 20kgf a low speeds.
Lead of Screw 0.5mm Per Thread
Typical Movement Sensitivity <100nm
Backlash <30um
Actuator Tip Flat Tip, Non Rotating
Motor Type 6V DC
Operation Enviornment 5-40 C, 20-80% Humidity (No condensation)
Length of Attached Cable 500mm (19.7 in.)
Mounting Interface Standard M9.5x0.5 Thread
Spindle Diameter 5mm (The spindle is non rotating)
Compatible Controllers SRC-101 and SRC-201
Compatible Extension cables MDC-4-2, MDC-4-3, MDC-4-5
i
17.5mm Travel, DC Motor Actuator, 9.5mm Threaded Shank, Non-rotating Spindle, 7kg Load
SGDC10-13F
17.5mm 68.6N (7.0kg)
in stock
$265.20
Travel 17.5mm
Travel Speed 0.2mm/sec at Max Load
Thrust Force 68.6N(7.0kgf) at Max Speed. Please note that the maximum thrust force can be over 20kgf a low speeds.
Lead of Screw 0.5mm Per Thread
Typical Movement Sensitivity <100nm
Backlash <30um
Actuator Tip Flat Tip, Non Rotating
Motor Type 6V DC
Operation Enviornment 5-40 C, 20-80% Humidity (No condensation)
Length of Attached Cable 500mm (19.7 in.)
Mounting Interface Standard M9.5x0.5 Thread
Spindle Diameter 5mm (The spindle is non rotating)
Compatible Controller SRC-101
Compatible Extension cables MDC-4-2, MDC-4-3, MDC-4-5

You must be logged in to ask questions

◦A customer can remove the micrometer head on its own and replace it with the remote actuator.
◦It is possible to select the movement amount of 13mm and 25mm depending on the application.
◦Since the USB interface is a standard feature, it can easily be operated from the PC.
◦Since the remote control is possible, it can also be used in a hard place to work as well as a little place.
