Cage High Stability Plate

C60-HSP

Cage High Stability Plate
In stock
SKU
C60-HSP
A holding plate that is more stable than standard post with fixing screws by clamping with the slotting and the bolts.
custom product
Customize product
Filters
Enabled filters :
Remove all filters

Attention ▶If the rod is tightened too tightly or if the tightening force is greatly different depending on the location, the rod may not fit in other holders.
▶Initially fix the rod lightly, after building the optical system, please tighten so that the force that fixes the rod is even in each holder.
▶When configuring a large optical system or a long optical system, it may become distorted or become unstable due to vibration.

Name Delivery Price Add to cart
i
Cage High Stability Plate
C60-HSP-50.8
2 weeks
$63.00
Primary material Aluminum
Guide Rod Diameter (Spaceing between rod) φ6mm (30x30mm)
Compatible Optics Diameter φ50.8mm
Compatible Optics Thickness - 9mm
Clear Aperture φ47mm
Installation Slide from the end of rods
i
Cage High Stability Plate
C60-HSP-50.8UU
2 weeks
$63.00
Primary material Aluminum
Guide Rod Diameter (Spaceing between rod) φ6mm (30x30mm)
Compatible Optics Diameter φ50.8mm
Compatible Optics Thickness - 9mm
Clear Aperture φ47mm
Installation Slide from the end of rods
