Small Kinematic Mirror Holder for 50mm Optic

MMH-50H

Skip to the beginning of the images gallery

Compact mirror holders with minimum necessary functions.
Compatible with various sizes of mirrors by attaching the mirror to the holder using adhesive. Appropriate for usage where operability of angle fine-tuning is not an issue and mirrors need to be placed within a limited space inside a device.

Details

More Information

More Information
Name	Small Kinematic Mirror Holder for 50mm Optic
Weight	0.2000kgs
Guide	□25mm square aluminum flat mirrors (TFA-25S05-10) and □50mm square aluminum flat mirrors (TFA-50S08-10) are available.（WEB Reference Catalog Code/W3403）
Attention	When mirrors are bonded to holders, stress exerted by hardening of adhesive may deteriorate the surface accuracy of mirrors. Use silicon adhesive that has less stress when optical systems require surface accuracy of mirrors such as interferometers or laser processing. Mirrors may not be removed once they are bonded. Holder performance will deteriorate if trying to remove mirrors by force, or keeping holders in high temperature for a prolonged time. Bond mirrors carefully to avoid failure. Since these are kinematic mirror holders, the rotation center of the fine-adjustment mechanism is not on the reflective surface of mirror.Gimbal mirror holders (MHAN) that have the rotation center of fine adjustment on the reflective surface of mirror are also available. (WEB Reference Catalog Code/D018)
Image Label	Small Kinematic Mirror Holder for 50mm Optic
Compatible Optics Diameter	＜□50mm/φ40mm
Fine-Adjustment Range /Tilt	±4°
Fine-Adjustment Range /Rotation	±4°
Resolution /Tilt	about 0.38°/rotation
Resolution /Rotation	about 0.38°/rotation

In stock

SKU

MMH-50H

$221.00
