Hollow Retro-Reflectors

RCCB

Hollow Retro-Reflectors
In stock
SKU
RCCB
The hollow retro-reflector is similar to the corner cube; it reflects the incident light back to its original source. This is made of a high precision assembly of 3 flat mirrors; insensitive to chromatic dispersion of the refractive index of glass and the absorptive of glass.
custom product
Customize product
Filters
Enabled filters :
Remove all filters
Name Length Delivery Price Add to cart
i
Hollow Retro-reflector 8mm Diameter 10 second Beam Deviation
RCCB-10-10
10mm
2 weeks
$955.00
Material BK7
Material propreties Aluminum (Finishing ; Black Anodized)
Coating Aluminum (Without protective coating)
Laser Damage Threshold 0.25J/cm2
Clear aperture φ8mm
Angular deviation of beam <10″
Reflected wavefront distortion
i
Hollow Retro-reflector 18mm Diameter 30 second Beam Deviation
RCCB-20-30
20mm
2 weeks
$477.00
Material BK7
Material properties Aluminum (Finishing ; Black Anodized)
Coating Aluminum (Without protective coating)
Laser Damage Threshold 0.25J/cm2
Clear aperture φ18mm
Angular deviation of beam <30″
Reflected wavefront distortion
i
Hollow Retro-reflector 8mm Diameter 30 second Beam Deviation
RCCB-10-30
10mm
6-12 weeks
$573.00
Material BK7
Material propreties Aluminum (Finishing ; Black Anodized)
Coating Aluminum (Without protective coating)
Laser Damage Threshold 0.25J/cm2
Clear aperture φ8mm
Angular deviation of beam <30″
Reflected wavefront distortion
i
Hollow Retro-reflector 27mm Diameter 5 second Beam Deviation
RCCB-30-5
30mm
6-12 weeks
$636.00
Material BK7
Material propreties Aluminum (Finishing ; Black Anodized)
Coating Aluminum (Without protective coating)
Laser Damage Threshold 0.25J/cm2
Clear aperture φ27mm
Angular deviation of beam <5″
Reflected wavefront distortion
i
Hollow Retro-reflector 8mm Diameter 5 second Beam Deviation
RCCB-20-5
20mm
6-12 weeks
$743.00
Material BK7
Material propreties Aluminum (Finishing ; Black Anodized)
Coating Aluminum (Without protective coating)
Laser Damage Threshold 0.25J/cm2
Clear aperture φ18mm
Angular deviation of beam <5″
Reflected wavefront distortion
i
Hollow Retro-reflector 27mm Diameter 30 second Beam Deviation
RCCB-30-30
30mm
6-12 weeks
$477.00
Material BK7
Material propreties Aluminum (Finishing ; Black Anodized)
Coating Aluminum (Without protective coating)
Laser Damage Threshold 0.25J/cm2
Clear aperture φ27mm
Angular deviation of beam <30″
Reflected wavefront distortion

You must be logged in to ask questions

◦The hollow is fabricated under high precision process; it can assure the reflection of high accuracy light.
◦Can be used at broad wavelength range from UV to IR.
◦Since there is no glass chromatic dispersion, the position of the back incident beam does not change with wavelength.
◦With a small polarization effects, it is recommended to use in multiple interferometer optical path.
