Aluminum Concave Mirror Protective Coated 10mm Diameter 400mm Focal Length
TCA-10C05-800
Coatings on all concave mirror substrate models are available. Pre-coated aluminum concave mirrors are available. These substrates are mainly used as the primary mirror in a reflecting telescope or as reflection mirror of a collimating optical system light-source.
◦Large selection from outer size to radius of curvature is available on our website and in our catalog.
◦Contact our Sales Division for your choice of coating specifications.
◦Contact our Sales Division for your choice of coating specifications.
| Name | Aluminum Concave Mirror Protective Coated 10mm Diameter 400mm Focal Length |
|---|---|
| Weight | 0.0050kgs |
| Standard Coatings Available | No |
| Guide |
|
| Remark | - |
| Attention |
|
| Diameter φD | 10mm |
| Focal length | 400mm |
| Image Label | Aluminum Concave Mirror Protective Coated 10mm Diameter 400mm Focal Length |
| Material | BK7 |
| Spherical surface accuracy | λ/2 |
| Curvature radius tolerance | ±2% |
| Coating | Al+MgF2 |
| Clear aperture | 85% of the diameter |
| Surface Quality <br> (Scratch-Dig) | 40-20 |
| Diameter φD | φ10mm |
| Edge thickness te | 5mm |
| Center thickness tc | 5mm |
| Radius of curvature r | 800mm |
| Focal length f | 400mm |
In stock
SKU
TCA-10C05-800
$84.00
Customize product
Coatings on all concave mirror substrate models are available. Pre-coated aluminum concave mirrors are available. These substrates are mainly used as the primary mirror in a reflecting telescope or as reflection mirror of a collimating optical system light-source.
