Interference Filters

Interference Filters

SKU : YIF

In stock
SKU
YIF
YIF is a filter that can extract a selected light from the wavelength range. Its primary feature is the ability to pick out a high transmittance wavelength at the same time cutting off a wavelength.
Name Delivery Price Add to cart
Interference Filter 25mm Diameter Transmit Range 517 - 542nm
YIF-BA510-550S
3-6 weeks
$380.00
Interference Filter 25mm Diameter Transmit Range 607 - 680nm
YIF-BA600-690S
5-10 days
$380.00
Interference Filter 25mm Diameter Transmit Range 430 - 520nm
YIF-BA420IFS
3-6 weeks
$300.00
Interference Filter 25mm Diameter Transmit Range 580 - 700nm
YIF-BA575IFS
5-10 days
$300.00
Interference Filter 25mm Diameter Transmit Range 470 - 503nm
YIF-BA460-510S
3-6 weeks
$380.00
Interference Filter 25mm Diameter Transmit Range 522 - 552nm
YIF-BA515-560S
3-6 weeks
$380.00
Interference Filter 25mm Diameter Transmit Range 470 - 650nm
YIF-BA460IFS
3-6 weeks
$300.00
Interference Filter 25mm Diameter Transmit Range 607 - 700nm
YIF-BA600IFS
3-6 weeks
$300.00
Interference Filter 25mm Diameter Transmit Range 499 - 535nm
YIF-BA495-540S
5-10 days
$380.00
Interference Filter 25mm Diameter Transmit Range 580 - 618nm
YIF-BA575-625S
3-6 weeks
$380.00
Interference Filter 25mm Diameter Transmit Range 517 - 700nm
YIF-BA510IFS
5-10 days
$300.00
Interference Filter 25mm Diameter Transmit Range 430 - 460nm
YIF-BA420-460S
3-6 weeks
$380.00
Interference Filter 25mm Diameter Transmit Range 360 - 380nm
YIF-BP340-390S
3-6 weeks
$400.00
Interference Filter 25mm Diameter Transmit Range 545 - 579nm
YIF-BP540-585S
3-6 weeks
$400.00
Interference Filter 25mm Diameter Transmit Range 465 - 476nm
YIF-BP460-480S
3-6 weeks
$400.00
Interference Filter 25mm Diameter Transmit Range 538 - 547nm
YIF-BP530-550S
5-10 days
$400.00
Interference Filter 25mm Diameter Transmit Range 403 - 436nm
YIF-BP400-440S
3-6 weeks
$400.00
Interference Filter 25mm Diameter Transmit Range 365nm
YIF-BP360-370S
3-6 weeks
$400.00
Interference Filter 25mm Diameter Transmit Range 478 - 489nm
YIF-BP470-495S
3-6 weeks
$400.00
Interference Filter 25mm Diameter Transmit Range 546nm
YIF-BP540-550S
3-6 weeks
$400.00
Interference Filter 25mm Diameter Transmit Range 464 - 489nm
YIF-BP460-495S
3-6 weeks
$400.00
Interference Filter 25mm Diameter Transmit Range 403 - 407nm
YIF-BP400-410S
in stock
$400.00
Interference Filter 25mm Diameter Transmit Range 492 - 498nm
YIF-BP490-500S
3-6 weeks
$400.00
Interference Filter 25mm Diameter Transmit Range 572 - 579nm
YIF-BP565-585S
3-6 weeks
$400.00

You must be logged in to ask questions

◦The filters are made by Ion Beam assisted dielectric coating process which can assure an extremely high environment resistance and high stability.
◦Using high absorption glass material and heat absorption optical coating, it assures a low deterioration with any types of light-source.
◦The filters were designed as the BP type light blocking characteristics of high OD7 at the long wavelength side than the pass band and the BA type light blocking characteristics of high OD7 at the short wavelength side of than the transmission bandwidth.
◦The filters can be used to cut the non-irradiated light wavelength excitation in fluorescence observation and cut the non fluorescence wavelength excitation light in sample observation.
◦In addition to the BP type filter and the BA type filter, there are broadband type and narrowband type that can be chosen according to your application.
