Rolling Frame, Elastomerically Isolated, Fixed-Level Optical Tables,

OSDVIO-R-USA

Rolling Frame, Elastomerically Isolated, Fixed-Level Optical Tables,
In stock
SKU
OSDVIO-R-USA
Entry-level, elastomerically isolated optical tables provide a basic level of vibration isolation for non-critical experiments.
custom product
Customize product
Name
Support Type
A x B
H
Load Capacity
Mounting Thread
Delivery Price Add to cart
Rigid 5'x4' 36" 1400kg 1/4-20UNC
5-6 weeks
$7,954.00
Threaded Holes 1/4-20-on-1" Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.
Rigid 12'x5' 36" 1600kg 1/4-20UNC
5-6 weeks
$19,366.00
Threaded Holes 1/4-20-on-1" Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.
Rigid 1200mm x 700mm 900mm 1500kg M6
5-6 weeks
$5,323.00
Threaded Holes M6-on-25mm Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.1m
Rigid 5'x5' 36" 1300kg 1/4-20UNC
5-6 weeks
$9,095.00
Threaded Holes 1/4-20-on-1" Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.
Rigid 1800mm x 700mm 900mm 1500kg M6
5-6 weeks
$6,988.00
Threaded Holes M6-on-25mm Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.1m
Rigid 10'x3' 36" 1200kg 1/4-20UNC
5-6 weeks
$11,589.00
Threaded Holes 1/4-20-on-1" Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.
Rigid 2400mm x 1500mm 900mm 1100kg M6
5-6 weeks
$13,572.00
Threaded Holes M6-on-25mm Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.1m
Rigid 5'x2' 36" 1500kg 1/4-20UNC
5-6 weeks
$4,881.00
Threaded Holes 1/4-20-on-1" Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.
Rigid 1200mm x 900mm 900mm 1500kg M6
5-6 weeks
$5,251.00
Threaded Holes M6-on-25mm Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.1m
Rigid 12'x4' 36" 900kg 1/4-20UNC
5-6 weeks
$16,259.00
Threaded Holes 1/4-20-on-1" Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.
Rigid 1800mm x 900mm 900mm 1400kg M6
5-6 weeks
$7,304.00
Threaded Holes M6-on-25mm Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.1m
Rigid 3000mm x 900mm 900mm 1200kg M6
5-6 weeks
$11,589.00
Threaded Holes M6-on-25mm Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.1m
Rigid 1500mm x 600mm 900mm 1500kg M6
5-6 weeks
$4,881.00
Threaded Holes M6-on-25mm Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.1m
Rigid 2000mm x 1200mm 900mm 1300kg M6
5-6 weeks
$9,306.00
Threaded Holes M6-on-25mm Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.1m
Rigid 3600mm x 1200mm 900mm 1700kg M6
5-6 weeks
$16,259.00
Threaded Holes M6-on-25mm Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.1m
Rigid 6'x5' 36" 1300kg 1/4-20UNC
5-6 weeks
$10,272.00
Threaded Holes 1/4-20-on-1" Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.
Rigid 4'x3' 36" 1500kg 1/4-20UNC
5-6 weeks
$5,251.00
Threaded Holes 1/4-20-on-1" Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.
Rigid 1500mm x 700mm 900mm 1500kg M6
5-6 weeks
$6,138.00
Threaded Holes M6-on-25mm Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.1m
Rigid 6'x3' 36" 1400kg 1/4-20UNC
5-6 weeks
$7,304.00
Threaded Holes 1/4-20-on-1" Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.
Rigid 1800mm x 1500mm 900mm 1300kg M6
5-6 weeks
$10,272.00
Threaded Holes M6-on-25mm Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.1m
Rigid 10'x5' 36" 1700kg 1/4-20UNC
5-6 weeks
$16,592.00
Threaded Holes 1/4-20-on-1" Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.
Rigid 3000mm x 1200mm 900mm 1100kg M6
5-6 weeks
$13,380.00
Threaded Holes M6-on-25mm Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.1m
Rigid 6'x2' 36" 1500kg 1/4-20UNC
5-6 weeks
$6,705.00
Threaded Holes 1/4-20-on-1" Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.
Rigid 1500mm x 900mm 900mm 1500kg M6
5-6 weeks
$6,795.00
Threaded Holes M6-on-25mm Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.1m
Rigid 2000mm x 1000mm 900mm 1400kg M6
5-6 weeks
$8,165.00
Threaded Holes M6-on-25mm Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.1m
Rigid 3000mm x 1500mm 900mm 1700kg M6
5-6 weeks
$16,592.00
Threaded Holes M6-on-25mm Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.1m
Rigid 1500mm x 1000mm 900mm 1400kg M6
5-6 weeks
$7,076.00
Threaded Holes M6-on-25mm Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.1m
Rigid 2400mm x 1200mm 900mm 1200kg M6
5-6 weeks
$10,856.00
Threaded Holes M6-on-25mm Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.1m
Rigid 3'x3' 36" 1600kg 1/4-20UNC
5-6 weeks
$4,636.00
Threaded Holes 1/4-20-on-1" Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.
Rigid 8'x5' 36" 1100kg 1/4-20UNC
5-6 weeks
$13,572.00
Threaded Holes 1/4-20-on-1" Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.
Rigid 900mm x 900mm 900mm 1600kg M6
5-6 weeks
$4,636.00
Threaded Holes M6-on-25mm Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.1m
Rigid 5'x3' 36" 1500kg 1/4-20UNC
5-6 weeks
$6,795.00
Threaded Holes 1/4-20-on-1" Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.
Rigid 1500mm x 1200mm 900mm 1400kg M6
5-6 weeks
$7,954.00
Threaded Holes M6-on-25mm Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.1m
Rigid 8'x3' 36" 1300kg 1/4-20UNC
5-6 weeks
$9,517.00
Threaded Holes 1/4-20-on-1" Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.
Rigid 2000mm x 1500mm 900mm 1200kg M6
5-6 weeks
$10,833.00
Threaded Holes M6-on-25mm Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.1m
Rigid 4'x2' 36" 1600kg 1/4-20UNC
5-6 weeks
$4,609.00
Threaded Holes 1/4-20-on-1" Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.
Rigid 1000mm x 700mm 900mm 1600kg M6
5-6 weeks
$5,137.00
Threaded Holes M6-on-25mm Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.1m
Rigid 8'x4' 36" 1200kg 1/4-20UNC
5-6 weeks
$10,856.00
Threaded Holes 1/4-20-on-1" Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.
Rigid 1500mm x 1500mm 900mm 1300kg M6
5-6 weeks
$9,095.00
Threaded Holes M6-on-25mm Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.1m
Rigid 2400m x 900mm 900mm 1300kg M6
5-6 weeks
$9,517.00
Threaded Holes M6-on-25mm Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.1m
Rigid 1200mm x 600mm 900mm 1600kg M6
5-6 weeks
$4,609.00
Threaded Holes M6-on-25mm Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.1m
Rigid 1800mm x 600mm 900mm 1500kg M6
5-6 weeks
$6,705.00
Threaded Holes M6-on-25mm Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.1m
Rigid 3000mm x 1000mm 900mm 1200kg M6
5-6 weeks
$12,414.00
Threaded Holes M6-on-25mm Matrix
Isolation Type Fixed Level, Passive Isolation
Damping Broadband
Surface Flatness ±0.1m

You must be logged in to ask questions

â—¦The internal aluminum honeycomb structure provides a lightweight and stiff structure.
â—¦The vibration-isolating frame has load capacity and stability.
â—¦The top surface of the bench is a magnetic stainless steel plate, with tapped holes (M6 or 1/4-20 thread matrix) over the entire surface.
