25x25mm Square, Brass, Dovetail Rotation Stage, +/-3 Deg Fine Adjustment, Hex Screw Drive, M2 Threads
KSSA-256
×
The KSSA stages are fine rotation stages having a square table top. These stages are suitable for making minute angle adjustment in applicationswhere a minimasl footprint is desirrd.
| Name | 25x25mm Square, Brass, Dovetail Rotation Stage, +/-3 Deg Fine Adjustment, Hex Screw Drive, M2 Threads |
|---|---|
| Weight | 0.0900kgs |
| Guide |
|
| Attention |
|
| Image Label | Rotation Stage Brass 25mm Square 6 Degree Fine Screw Adjustment and Lockable with Metric Holes |
| Stage Size | 25×25mm |
| Rotation Range | ±3° |
| Load Capacity | 29.4N (3.0kg) |
| Mounting Thread | M2 |
| Stage Size | 25×25mm |
| Rotation Range | ±3° |
| Scale Readable Resolution | - |
| Micrometer Readable Resolution | about 3.18° |
| Guide Method | Dovetail method |
| Primary Material | Brass |
| Finish | Super black chrome |
| Load Capacity | 29.4N(3.0kgf) |
| Max. Moment Capacity | - |
| Moment Stiffness | 2.0″/N･cm |
| Parallelism | 50μm |
| Eccentricity | - |
| Wobble | - |
In stock
SKU
KSSA-256
$299.00
Customize product
The KSSA stages are fine rotation stages having a square table top. These stages are suitable for making minute angle adjustment in applicationswhere a minimasl footprint is desirrd.
