Center-Drive Standard EXC Steel XY Stages

TSD-2-C

Center-Drive Standard EXC Steel XY Stages
In stock
SKU
TSD-2-C
The TSD-C stages (with center-drive micrometers) feature Opto Sigma's EXC™ precision bearing ways. These bearing ways are not separate parts, as with competing stages, but processed directly into the body and base of the stage resulting in the highest stiffness, straightness and smoothness of any stage on the market. They remain unmatched in overall performance to this day. All TSD stages are made entirely from hardened tool steel and are plated with an RoHS-compliant black chrome. These XY stages are integrated and therefore have a lower profile vs. two single-axis stages combined.
custom product
Customize product
Filters
Enabled filters :
Remove all filters
Name Stage Size Travel Load Capacity Mounting Thread Delivery Price Add to cart
i
40X40mm EXC Bearing, Steel, XY-Axis Stage, Center 90-Deg. Micrometer, +/-6.5mm, 6-32 Threads
TSD-402CDLUU
40×40mm ±6.5mm 196N (20.0kg) 6-32UNC
6-12 weeks
$964.00
Micrometer Position Center
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
i
60X60mm EXC Bearing, Steel, XY-Axis Stage, Center Differential Micrometer, +/-6.5mm, M4 Threads
TSD-602CDM
60×60mm ±6.5mm 343N (35.0kg) M4
6-12 weeks
$1,395.00
Micrometer Position Center
Lead of Actuator Coarse:0.5mm Fine:0.025mm
Micrometer Readable Resolution Coarse:0.01mm Fine:0.0005mm
i
65X65mm EXC Bearing, Steel, XY-Axis Stage, Center Micrometer, +/-6.5mm, M6 Threads
TSD-652C-M6
65×65mm ±6.5mm 294N (30.0kg) M6
in stock
$811.00
Micrometer Position Center
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
i
65X65mm EXC Bearing, Steel, XY-Axis Stage, Center Micrometer, +/-12.5mm, 1/4-20 Threads
TSD-652C25UU
65×65mm ±12.5mm 294N (30.0kg) 1/4-20UNC
in stock
$811.00
Micrometer Position Center
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
i
65X65mm EXC Bearing, Steel, XY-Axis Stage, Center Sub-Micron Worm-screw Micrometer, +/-6.5mm, M6 Threads
TSD-652CWP-M6
65×65mm ±6.5mm 294N (30.0kg) M6
6-12 weeks
$1,192.00
Micrometer Position Center
Lead of Actuator Coarse:0.25mm Fine:0.005mm
Micrometer Readable Resolution Coarse :0.005mm Fine :0.0005mm
i
65X65mm EXC Bearing, Steel, XY-Axis Stage, Center Differential Micrometer, +/-6.5mm, 1/4-20 Threads
TSD-652CDMUU
65×65mm ±6.5mm 294N (30.0kg) 1/4-20UNC
6-12 weeks
$1,496.00
Micrometer Position Center
Lead of Actuator Coarse :0.5mm Fine :0.025mm
Micrometer Readable Resolution Coarse :0.01mm Fine :0.0005mm
i
65X65mm EXC Bearing, Steel, XY-Axis Stage, Center Hex Screw, +/-12.5mm, M6 Threads
TSD-652CFP25-M6
65×65mm ±12.5mm 294N (30.0kg) M6
2-3 weeks
$735.00
Micrometer Position Center
Lead of Actuator 0.25mm
Micrometer Readable Resolution -
i
80X80mm EXC Bearing, Steel, XY-Axis Stage, Center Hex Screw, +/-12.5mm, M4 Threads
TSD-802CFP
80×80mm ±12.5mm(±6.5mm for SDM and SWP) 490N (50.0kg) M4
6-12 weeks
$837.00
Micrometer Position Center
Lead of Actuator 0.25mm
Micrometer Readable Resolution -
i
25X25mm EXC Bearing, Steel, XY-Axis Stage, Center Hex Screw, +/-3mm, M2 Threads
TSD-252CFP
25×25mm ±3mm 49N (5.0kg) M2
6-12 weeks
$482.00
Micrometer Position Center
Lead of Actuator 0.25mm
Micrometer Readable Resolution -
i
100X100mm EXC Bearing, Steel, XY-Axis Stage, Center Micrometer, +/-12.5mm, M4 Threads
TSD-1002C
100×100mm ±12.5mm 588N (60.0kg) M4
2 weeks
$964.00
Micrometer Position Center
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
i
40X40mm EXC Bearing, Steel, XY-Axis Stage, Center Micrometer, +/-6.5mm, 6-32 Threads
TSD-402CUU
40×40mm ±6.5mm 196N (20.0kg) 6-32UNC
in stock
$634.00
Micrometer Position Center
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
i
120X120mm EXC Bearing, Steel, XY-Axis Stage, Center Micrometer, +/-20mm, M4 Threads
TSD-1202CH
120×120mm ±20mm 686N (70.0kg) M4
6-12 weeks
$1,217.00
Micrometer Position Center
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
i
40X40mm EXC Bearing, Steel, XY-Axis Stage, Center Sub-Micron Worm-screw Micrometer, +/-6.5mm, M3 Threads
TSD-402CWP
40×40mm ±6.5mm 196N (20.0kg) M3
6-12 weeks
$1,014.00
Micrometer Position Center
Lead of Actuator Coarse:0.25mm Fine:0.005mm
Micrometer Readable Resolution Coarse:0.005mm Fine:0.0005mm
i
40X40mm EXC Bearing, Steel, XY-Axis Stage, Center Differential Micrometer, +/-6.5mm, 6-32 Threads
TSD-402CDMUU
40×40mm ±6.5mm 196N (20.0kg) 6-32UNC
6-12 weeks
$1,319.00
Micrometer Position Center
Lead of Actuator Coarse:0.5mm Fine:0.025mm
Micrometer Readable Resolution Coarse:0.01mm Fine:0.0005mm
i
60X60mm EXC Bearing, Steel, XY-Axis Stage, Center Micrometer, +/-6.5mm, M4 Threads
TSD-602C
60×60mm ±6.5mm 343N (35.0kg) M4
6-12 weeks
$710.00
Micrometer Position Center
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
i
60X60mm EXC Bearing, Steel, XY-Axis Stage, Center Sub-Micron Worm-screw Micrometer, +/-6.5mm, M4 Threads
TSD-602CWP
60×60mm ±6.5mm 343N (35.0kg) M4
6-12 weeks
$1,090.00
Micrometer Position Center
Lead of Actuator Coarse:0.25mm Fine:0.005mm
Micrometer Readable Resolution Coarse:0.005mm Fine:0.0005mm
i
65X65mm EXC Bearing, Steel, XY-Axis Stage, Center Micrometer, +/-6.5mm, 1/4-20 Threads
TSD-652CUU
65×65mm ±6.5mm 294N (30.0kg) 1/4-20UNC
in stock
$811.00
Micrometer Position Center
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
i
65X65mm EXC Bearing, Steel, XY-Axis Stage, Center Hex Screw, +/-6.5mm, M6 Threads
TSD-652CFP-M6
65×65mm ±6.5mm 294N (30.0kg) M6
6-12 weeks
$735.00
Micrometer Position Center
Lead of Actuator 0.25mm
Micrometer Readable Resolution -
i
65X65mm EXC Bearing, Steel, XY-Axis Stage, Center 90-Deg. Micrometer, +/-6.5mm, M6 Threads
TSD-652CDL-M6
65×65mm ±6.5mm 294N (30.0kg) M6
6-12 weeks
$1,141.00
Micrometer Position Center
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
i
65X65mm EXC Bearing, Steel, XY-Axis Stage, Center Sub-Micron Worm-screw Micrometer, +/-6.5mm, 1/4-20 Threads
TSD-652CWPUU
65×65mm ±6.5mm 294N (30.0kg) 1/4-20UNC
2-3 weeks
$1,192.00
Micrometer Position Center
Lead of Actuator Coarse:0.25mm Fine:0.005mm
Micrometer Readable Resolution Coarse :0.005mm Fine :0.0005mm
i
65X65mm EXC Bearing, Steel, XY-Axis Stage, Center Hex Screw, +/-12.5mm, 1/4-20 Threads
TSD-652CFP25UU
65×65mm ±12.5mm 294N (30.0kg) 1/4-20UNC
2-3 weeks
$735.00
Micrometer Position Center
Lead of Actuator 0.25mm
Micrometer Readable Resolution -
i
80X80mm EXC Bearing, Steel, XY-Axis Stage, Center Differential Micrometer, +/-6.5mm, M4 Threads
TSD-802CDM
80×80mm ±12.5mm(±6.5mm for SDM and SWP) 490N (50.0kg) M4
6-12 weeks
$1,598.00
Micrometer Position Center
Lead of Actuator Coarse:0.5mm Fine:0.025mm
Micrometer Readable Resolution Coarse:0.01mm Fine:0.0005mm
i
25X25mm EXC Bearing, Steel, XY-Axis Stage, Center 90-Deg. Micrometer, +/-3mm, M2 Threads
TSD-252CDL
25×25mm ±3mm 49N (5.0kg) M2
6-12 weeks
$723.00
Micrometer Position Center
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
i
100X100mm EXC Bearing, Steel, XY-Axis Stage, Center Hex Screw, +/-12.5mm, M4 Threads
TSD-1002CFP
100×100mm ±12.5mm 588N (60.0kg) M4
2-3 weeks
$888.00
Micrometer Position Center
Lead of Actuator 0.25mm
Micrometer Readable Resolution -
i
40X40mm EXC Bearing, Steel, XY-Axis Stage, Center Hex Screw, +/-6.5mm, M3 Threads
TSD-402CFP
40×40mm ±6.5mm 196N (20.0kg) M3
6-12 weeks
$558.00
Micrometer Position Center
Lead of Actuator 0.25mm
Micrometer Readable Resolution -
i
120X120mm EXC Bearing, Steel, XY-Axis Stage, Center Micrometer, +/-20mm, M6 Threads
TSD-1202CH-M6
120×120mm ±20mm 686N (70.0kg) M6
in stock
$1,217.00
Micrometer Position Center
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
i
40X40mm EXC Bearing, Steel, XY-Axis Stage, Center 90-Deg. Micrometer, +/-6.5mm, M3 Threads
TSD-402CDL
40×40mm ±6.5mm 196N (20.0kg) M3
6-12 weeks
$964.00
Micrometer Position Center
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
i
40X40mm EXC Bearing, Steel, XY-Axis Stage, Center Sub-Micron Worm-screw Micrometer, +/-6.5mm, 6-32 Threads
TSD-402CWPUU
40×40mm ±6.5mm 196N (20.0kg) 6-32UNC
6-12 weeks
$1,014.00
Micrometer Position Center
Lead of Actuator Coarse:0.25mm Fine:0.005mm
Micrometer Readable Resolution Coarse:0.005mm Fine:0.0005mm
i
60X60mm EXC Bearing, Steel, XY-Axis Stage, Center Hex Screw, +/-6.5mm, M4 Threads
TSD-602CFP
60×60mm ±6.5mm 343N (35.0kg) M4
6-12 weeks
$634.00
Micrometer Position Center
Lead of Actuator 0.25mm
Micrometer Readable Resolution -
i
60X60mm EXC Bearing, Steel, XY-Axis Stage, Center 90-Deg. Micrometer, +/-6.5mm, M4 Threads
TSD-602CDL
60×60mm ±6.5mm 343N (35.0kg) M4
6-12 weeks
$1,040.00
Micrometer Position Center
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
i
65X65mm EXC Bearing, Steel, XY-Axis Stage, Center Micrometer, +/-12.5mm, M6 Threads
TSD-652C25-M6
65×65mm ±12.5mm 294N (30.0kg) M6
in stock
$811.00
Micrometer Position Center
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
i
65X65mm EXC Bearing, Steel, XY-Axis Stage, Center Differential Micrometer, +/-6.5mm, M6 Threads
TSD-652CDM-M6
65×65mm ±6.5mm 294N (30.0kg) M6
6-12 weeks
$1,496.00
Micrometer Position Center
Lead of Actuator Coarse :0.5mm Fine :0.025mm
Micrometer Readable Resolution Coarse :0.01mm Fine :0.0005mm
i
65X65mm EXC Bearing, Steel, XY-Axis Stage, Center Hex Screw, +/-6.5mm, 1/4-20 Threads
TSD-652CFPUU
65×65mm ±6.5mm 294N (30.0kg) 1/4-20UNC
2-3 weeks
$735.00
Micrometer Position Center
Lead of Actuator 0.25mm
Micrometer Readable Resolution -
i
65X65mm EXC Bearing, Steel, XY-Axis Stage, Center 90-Deg. Micrometer, +/-6.5mm, 1/4-20 Threads
TSD-652CDLUU
65×65mm ±6.5mm 294N (30.0kg) 1/4-20UNC
2-3 weeks
$1,141.00
Micrometer Position Center
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
i
80X80mm EXC Bearing, Steel, XY-Axis Stage, Center Micrometer, +/-12.5mm, M4 Threads
TSD-802C
80×80mm ±12.5mm(±6.5mm for SDM and SWP) 490N (50.0kg) M4
6-12 weeks
$913.00
Micrometer Position Center
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
i
25X25mm EXC Bearing, Steel, XY-Axis Stage, Center Micrometer, +/-3mm, M2 Threads
TSD-252C
25×25mm ±3mm 49N (5.0kg) M2
in stock
$558.00
Micrometer Position Center
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
i
80X80mm EXC Bearing, Steel, XY-Axis Stage, Center Sub-Micron Worm-screw Micrometer, +/-6.5mm, M4 Threads
TSD-802CWP
80×80mm ±12.5mm(±6.5mm for SDM and SWP) 490N (50.0kg) M4
6-12 weeks
$1,293.00
Micrometer Position Center
Lead of Actuator Coarse:0.25mm Fine:0.005mm
Micrometer Readable Resolution Coarse:0.005mm Fine:0.0005mm
i
40X40mm EXC Bearing, Steel, XY-Axis Stage, Center Micrometer, +/-6.5mm, M3 Threads
TSD-402C
40×40mm ±6.5mm 196N (20.0kg) M3
in stock
$634.00
Micrometer Position Center
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
i
100X100mm EXC Bearing, Steel, XY-Axis Stage, Center Digital Micrometer, +/-12.5mm, M4 Threads
TSD-1002CDG
100×100mm ±12.5mm 588N (60.0kg) M4
2 weeks
$1,293.00
Micrometer Position Center
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.001mm
i
40X40mm EXC Bearing, Steel, XY-Axis Stage, Center Differential Micrometer, +/-6.5mm, M3 Threads
TSD-402CDM
40×40mm ±6.5mm 196N (20.0kg) M3
6-12 weeks
$1,319.00
Micrometer Position Center
Lead of Actuator Coarse:0.5mm Fine:0.025mm
Micrometer Readable Resolution Coarse:0.01mm Fine:0.0005mm
i
120X120mm EXC Bearing, Steel, XY-Axis Stage, Center Micrometer, +/-20mm, 1/4-20 Threads
TSD-1202CHUU
120×120mm ±20mm 686N (70.0kg) 1/4-20UNC
in stock
$1,217.00
Micrometer Position Center
Lead of Actuator 0.5mm
Micrometer Readable Resolution 0.01mm
i
40X40mm EXC Bearing, Steel, XY-Axis Stage, Center Hex Screw, +/-6.5mm, 6-32 Threads
TSD-402CFPUU
40×40mm ±6.5mm 196N (20.0kg) 6-32UNC
6-12 weeks
$558.00
Micrometer Position Center
Lead of Actuator 0.25mm
Micrometer Readable Resolution -

You must be logged in to ask questions

Click here to receive announcements and exclusive promotions

Remind me later

Thank you! Please check your email inbox to confirm.

Oops! Notifications are disabled.
