670nm Laser Diode and Power Supply, 4.5 mW

LDU33-670-4.5

Low ripple and noise laser diode module and power supply.
Aspheric lens premounted and suitable for either a collimated beam or adjustable focus beam, and compact for adequate OEM.
◦ Easy adjustment of collimated beam size by using helicoid focusing ring.
◦ High quality APC power supply allows quick start and stable output.
◦ User friendly and easy to mount on adjustable holders.
More Information
Name 670nm Laser Diode and Power Supply, 4.5 mW
Weight 0.3500kgs
Standard Coatings Available No
Guide
  • For custom wavelengths, outputs and modulation, contact our International Sales Division for more information.
  • Can be mounted with the laser mount (MHG-20LDU) for the kinematic mirror holder. (WEB Reference Catalog Code/W4005)
Attention
  • Power supply voltage for the 405nm model is 9V.
Image Label Laser Diode (Visible)
Wavelength Range 670nm
Wavelength 670nm
CW Output 4.5mW
Laser Spot Size at Exit about 5×2mm
Drive Voltage 5V
In stock
SKU
LDU33-670-4.5
$609.00

Delivery in : 2 weeks

Low ripple and noise laser diode module and power supply.
Aspheric lens premounted and suitable for either a collimated beam or adjustable focus beam, and compact for adequate OEM.
