31.5mm Travel, DC Motor Actuator, 9.5mm Threaded Shank, Non-rotating Spindle, 3kg Load

SGDC10-25

CE
3d-simple-product
The SGCD low-cost DC motor actuators are open-loop and intended for simple automated or remote movement of linear stages or other precision positioners. SGDC Actuators are equipped with a thin-diameter 6V DC motor which provides exceptionally high-thrust loads. The actual diameter is only 10mm. All SGDC actuators have a non-rotating spindle which reduces contact-point friction and improves repeatability and durability. Using an SRC-series controller, incremental resolutions under 100nm are achievable. Also, at the slowest speeds, this actuator is capable moving loads exceeding 20 kgf. The standard 9.5mm threaded mounting shank allows these actuators to be mounted on most OptoSigma translation stages.



More Information
Name 31.5mm Travel, DC Motor Actuator, 9.5mm Threaded Shank, Non-rotating Spindle, 3kg Load
Weight 0.0600kgs
Guide
  • SGDC10-13、SGDC10-25 are classified into Category 9 (Monitoring and control instruments including industrial monitoring and control instruments), We declare CE by RoHS (restricted substances: 6 substances) since the application deadline of RoHS (restricted substances: 10 substances) is July 2021.
Attention When replacing the micrometer head on a manual translation stage with the SGDC actuator, please refer the technical guide. To remove or install the lock nut, use the MNS-12.5-14.5 nut driver. Please take care when handling cable. Shock, compression, bending, twisting, can damage or cause disconnection of the cable.
Image Label DC motor Acuator 9.5 mm shank 31.5mm of travel
Travel 31.5mm
Load Capacity 29.4N (3.0kg)
Travel 31.5mm
Travel Speed 1.0mm/sec at Max Load
Thrust Force 29.5N(3.0kgf) at Max Speed. Please note that the maximum thrust force can be over 20kgf a low speeds.
Lead of Screw 0.5mm Per Thread
Typical Movement Sensitivity <100nm
Backlash <30um
Actuator Tip Flat Tip, Non Rotating
Motor Type 6V DC
Operation Enviornment 5-40 C, 20-80% Humidity (No condensation)
Length of Attached Cable 500mm (19.7 in.)
Mounting Interface Standard M9.5x0.5 Thread
Spindle Diameter 5mm (The spindle is non rotating)
Compatible Controllers SRC-101 and SRC-201
Compatible Extension cables MDC-4-2, MDC-4-3, MDC-4-5
