Out of stock
SKU
FHRS|FHRSW
Rotating fiber holder with coarse/fine adjustment to rotate and align the polarization plane of polarization-maintaining fibers. It is used by attaching it to the holder mounting section of the alignment unit.
Customize product
Filters
Enabled filters :
Remove all filters
| Name | Delivery | Price | Add to cart | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
details
FHRSW-125|400R
|
Contact Us
|
€1,188.00
|
|
|||||||||||
|
details
FHRSW-125|250R
|
Contact Us
|
€1,188.00
|
|
|||||||||||
|
details
FHRS-125|900L
|
Contact Us
|
€1,155.00
|
|
|||||||||||
|
details
FHRS-125|250R
|
Contact Us
|
€1,155.00
|
|
|||||||||||
|
details
FHRSW-125|900R
|
Contact Us
|
€1,188.00
|
|
|||||||||||
|
details
FHRSW-125|400L
|
Contact Us
|
€1,188.00
|
|
|||||||||||
|
details
FHRS-125|400L
|
Contact Us
|
€1,155.00
|
|
|||||||||||
|
details
FHRS-125|900R
|
Contact Us
|
€1,155.00
|
|
|||||||||||
|
details
FHRSW-125|900L
|
Contact Us
|
€1,188.00
|
|
|||||||||||
|
details
FHRSW-125|250L
|
Contact Us
|
€1,188.00
|
|
|||||||||||
|
details
FHRS-125|400R
|
Contact Us
|
€1,155.00
|
|
|||||||||||
|
details
FHRS-125|250L
|
Contact Us
|
€1,155.00
|
|
You must be logged in to ask questions
The plastic pushers have built-in magnetizing set bolts, gently clamps the polarization-maintaining fiber by the magnetic force of the fiber holder's magnets.
Attachment to the fiber alignment unit is a one-touch operation using magnets for easy connection and disconnection.
Can be attached to the DAU series fiber alignment unit.
We have two types of fiber holders: the FHRSW series with a suction function at the tip and the FHRS series without a suction function. We also have three jacket diameters of 250 μm, 400 μm, and 900 μm. All cladding diameters are specified at 125 μm.
The FHRSW series comes with a vacuum suction tube (2m).
Attachment to the fiber alignment unit is a one-touch operation using magnets for easy connection and disconnection.
Can be attached to the DAU series fiber alignment unit.
We have two types of fiber holders: the FHRSW series with a suction function at the tip and the FHRS series without a suction function. We also have three jacket diameters of 250 μm, 400 μm, and 900 μm. All cladding diameters are specified at 125 μm.
The FHRSW series comes with a vacuum suction tube (2m).
