Out of stock
SKU
PBSHP
High Power Polarizing Beamsplitters have more laser durability compared to our standard Polarizing Beamsplitters (PBS). Polarizing beamsplitters consist of two right angle prisms. One of them is coated with dielectric multi-layer polarizing coating on the hypotenuse face.
Customize product
Filters
Enabled filters :
Remove all filters
Remark - The two elements of these polarizing beamsplitters are bonded by optical contact. No adhesive material is used. The bonding occurs due to intermolecular forces such as van der Waals forces or hydrogen bonding when the surfaces are brought into close contact, usually within a few angstroms.
| Name |
Design wavelength
|
Length
|
Material
|
Delivery | Price | Add to cart | |||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
details
PBSHPQ-20-10300
|
1030nm | 20mm | Synthetic fused silica |
1 week
|
€762.00
|
|
|
||||||||||||||||||||||||||
|
details
PBSHP-20-3550
|
355nm | 20mm | Synthetic fused silica |
4-6 weeks
|
€807.80
|
|
|
||||||||||||||||||||||||||
|
details
PBSHP-15-10640
|
1064nm | 15mm | BK7 |
4-6 weeks
|
€518.60
|
|
|
||||||||||||||||||||||||||
|
details
PBSHPQ-10-5320
|
532nm | 10mm | Synthetic fused silica |
1 week
|
€514.10
|
|
|
||||||||||||||||||||||||||
|
details
PBSHPQ-15-10640
|
1064nm | 15mm | Synthetic fused silica |
4-6 weeks
|
€577.70
|
|
|
||||||||||||||||||||||||||
|
details
PBSHPQ-20-5320
|
532nm | 20mm | Synthetic fused silica |
4-6 weeks
|
€762.00
|
|
|
||||||||||||||||||||||||||
|
details
PBSHPQ-15-5150
|
515nm | 15mm | Synthetic fused silica |
1 week
|
€577.70
|
|
|
||||||||||||||||||||||||||
|
details
PBSHP-15-2570
|
257nm | 15mm | Synthetic fused silica |
4-6 weeks
|
€635.80
|
|
|
||||||||||||||||||||||||||
|
details
PBSHP-12.7-3430
|
343nm | 12.7mm | Synthetic fused silica |
4-6 weeks
|
€560.00
|
|
|
||||||||||||||||||||||||||
|
details
PBSHPQ-12.7-5150
|
515nm | 12.7mm | Synthetic fused silica |
4-6 weeks
|
€514.10
|
|
|
||||||||||||||||||||||||||
|
details
PBSHPQ-12.7-10300
|
1030nm | 12.7mm | Synthetic fused silica |
4-6 weeks
|
€514.10
|
|
|
||||||||||||||||||||||||||
|
details
PBSHP-10-3550
|
355nm | 10mm | Synthetic fused silica |
1 week
|
€560.00
|
|
|
||||||||||||||||||||||||||
|
details
PBSHP-20-5320
|
532nm | 20mm | BK7 |
4-6 weeks
|
€683.60
|
|
|
||||||||||||||||||||||||||
|
details
PBSHP-20-10640
|
1064nm | 20mm | BK7 |
4-6 weeks
|
€683.60
|
|
|
||||||||||||||||||||||||||
|
details
PBSHPQ-12.7-10640
|
1064nm | 12.7mm | Synthetic fused silica |
4-6 weeks
|
€514.10
|
|
|
||||||||||||||||||||||||||
|
details
PBSHPQ-15-5320
|
532nm | 15mm | Synthetic fused silica |
1 week
|
€577.70
|
|
|
||||||||||||||||||||||||||
|
details
PBSHP-12.7-3550
|
355nm | 12.7mm | Synthetic fused silica |
4-6 weeks
|
€560.00
|
|
|
||||||||||||||||||||||||||
|
details
PBSHP-10-2570
|
257nm | 10mm | Synthetic fused silica |
4-6 weeks
|
€565.30
|
|
|
||||||||||||||||||||||||||
|
details
PBSHP-12.7-5320
|
532nm | 12.7mm | BK7 |
4-6 weeks
|
€461.10
|
|
|
||||||||||||||||||||||||||
|
details
PBSHP-20-2570
|
257nm | 20mm | Synthetic fused silica |
4-6 weeks
|
€831.20
|
|
|
||||||||||||||||||||||||||
|
details
PBSHP-15-3430
|
343nm | 15mm | Synthetic fused silica |
4-6 weeks
|
€624.20
|
|
|
||||||||||||||||||||||||||
|
details
PBSHPQ-20-5150
|
515nm | 20mm | Synthetic fused silica |
4-6 weeks
|
€762.00
|
|
|
||||||||||||||||||||||||||
|
details
PBSHPQ-15-10300
|
1030nm | 15mm | Synthetic fused silica |
4-6 weeks
|
€577.70
|
|
|
||||||||||||||||||||||||||
|
details
PBSHP-15-3550
|
355nm | 15mm | Synthetic fused silica |
in stock
|
€624.20
|
|
|
||||||||||||||||||||||||||
|
details
PBSHP-10-10640
|
1064nm | 10mm | BK7 |
4-6 weeks
|
€461.10
|
|
|
||||||||||||||||||||||||||
|
details
PBSHPQ-10-10640
|
1064nm | 10mm | Synthetic fused silica |
1 week
|
€514.10
|
|
|
||||||||||||||||||||||||||
|
details
PBSHPQ-12.7-5320
|
532nm | 12.7mm | Synthetic fused silica |
4-6 weeks
|
€514.10
|
|
|
||||||||||||||||||||||||||
|
details
PBSHPQ-20-10640
|
1064nm | 20mm | Synthetic fused silica |
4-6 weeks
|
€762.00
|
|
|
||||||||||||||||||||||||||
|
details
PBSHPQ-10-5150
|
515nm | 10mm | Synthetic fused silica |
1 week
|
€514.10
|
|
|
||||||||||||||||||||||||||
|
details
PBSHP-12.7-2570
|
257nm | 12.7mm | Synthetic fused silica |
1 week
|
€565.30
|
|
|
||||||||||||||||||||||||||
|
details
PBSHP-12.7-10640
|
1064nm | 12.7mm | BK7 |
4-6 weeks
|
€461.10
|
|
|
||||||||||||||||||||||||||
|
details
PBSHP-10-3430
|
343nm | 10mm | Synthetic fused silica |
4-6 weeks
|
€560.00
|
|
|
||||||||||||||||||||||||||
|
details
PBSHP-20-3430
|
343nm | 20mm | Synthetic fused silica |
1 week
|
€807.80
|
|
|
||||||||||||||||||||||||||
|
details
PBSHPQ-10-10300
|
1030nm | 10mm | Synthetic fused silica |
1 week
|
€514.10
|
|
|
You must be logged in to ask questions
◦Polarizing beamsplitters split a monochromatic beam entering at zero degrees into p-polarization as transmitted and s-polarization as reflected.
◦Four surfaces of the cube are coated with narrowband multi-layer anti-reflection coating.
◦The losses of input beam of these products are minimized because of no absorption resulting from the dielectric coating.
◦For cube beamsplitters, unlike plate beamsplitters, beam deviations of transmitted beams and ghosts rarely occur.
◦Four surfaces of the cube are coated with narrowband multi-layer anti-reflection coating.
◦The losses of input beam of these products are minimized because of no absorption resulting from the dielectric coating.
◦For cube beamsplitters, unlike plate beamsplitters, beam deviations of transmitted beams and ghosts rarely occur.
