Core Unit Microscope (Constucted)

CUS_SET

Out of stock

SKU

CUS_SET

CUS-SET is a constucted and ready to use Core Unit Microscope.

Customize product

Filters

Remove all filters

Name Delivery Price Add to cart

details

CUSmini-BF

contactus

Type	Inverted microscope for bright field observation
Dimension of breadboard	450 × 350 mm
Dimension of sample stage	-
Dimension of main body of microscope	287.2×145.9 mm
Travel range of sample stage	X axis : ±6.5mm, Y axis : ±6.5mm, Z axis : ±6.5mm
Objective lens mount	M25×0.75
Par forcal length of objective lens	60ｍｍ
Attached objective lens	CFl Plan Fluor 100xH(Oil), WD = 0.16 mm
Imaging lens	Imaging lens from Nikon (f=200mm)
Magnification	100x (with attached objective lens)
Camera Mount	C mount
Attached camera	ARGO CORPORATION, DMK33G618
Actual field of view	35.8 x 26.9 mm (with attached camera and objective lens)
Illumination	LED Spot Illumination (White)

details

CUS-BF

contactus

Type	Inverted microscope for bright field observation
Dimension of breadboard	450 × 350 mm
Dimension of sample stage	225 × 225 mm
Dimension of main body of microscope	-
Travel range of sample stage	X axis : ±12.5mm, Y axis : ±6.5mm, Z axis : ±6.5mm
Objective lens mount	M25×0.75
Par forcal length of objective lens	60ｍｍ
Attached objective lens	CFl Plan Fluor 100xH(Oil), WD = 0.16 mm
Imaging lens	Imaging lens from Nikon (f=200mm)
Magnification	100x (with attached objective lens)
Camera Mount	C mount
Attached camera	ARGO CORPORATION, DMK33G618
Actual field of view	35.8 x 26.9 mm (with attached camera and objective lens)
Illumination	LED Spot Illumination (White)
