Aluminum Concave Mirror Without Protective Coating 30mm Diameter 5000mm Focal Length
TCAN-30C05-10000
Coatings on all concave mirror substrate models are available. Pre-coated aluminum concave mirrors are available. These substrates are mainly used as the primary mirror in a reflecting telescope or as reflection mirror of a collimating optical system light-source.
◦Large selection from outer size to radius of curvature is available on our website and in our catalog.
◦Contact our Sales Division for your choice of coating specifications.
◦Contact our Sales Division for your choice of coating specifications.
| Name | Aluminum Concave Mirror Without Protective Coating 30mm Diameter 5000mm Focal Length |
|---|---|
| Weight | 0.0090kgs |
| Standard Coatings Available | No |
| Guide |
|
| Remark | - |
| Attention |
|
| Diameter φD | 30mm |
| Focal length | 5000mm |
| Image Label | Aluminum Concave Mirror Without Protective Coating 30mm Diameter 5000mm Focal Length |
| Material | BK7 |
| Spherical surface accuracy | λ/2 |
| Curvature radius tolerance | ±2% |
| Coating | Aluminum (Without protective coating) |
| Clear aperture | 85% of the diameter |
| Surface Quality <br> (Scratch-Dig) | 40-20 |
| Diameter φD | φ30mm |
| Edge thickness te | 5mm |
| Center thickness tc | 5mm |
| Radius of curvature r | 10000mm |
| Focal length f | 5000mm |
In stock
SKU
TCAN-30C05-10000
₹9,768.00
Customize product
Coatings on all concave mirror substrate models are available. Pre-coated aluminum concave mirrors are available. These substrates are mainly used as the primary mirror in a reflecting telescope or as reflection mirror of a collimating optical system light-source.
