Objective lenses for NUV range

OUCI-OBJECTIVES-NUV

Objective lenses for NUV range
In stock
SKU
OUCI-OBJECTIVES-NUV
This objective lens can be used for laser machining using pulsed laser of THG (355nm) YAG laser. Chromatic aberration is suppressed in both the visible and UV laser wavelength, achieving a high transmittance.
custom product
Customize product
Filters
Enabled filters :
Remove all filters
Name Magnification Numerical Aperture Working Distance WD Delivery Price Add to cart
i
Near Ultra-violet (NUV) Objective Lens
PAL-100-NUV-HR
100× 0.7 10mm
6-12 weeks
-
Item name MplanApo NUV HR 100x
Focal length f 2mm
Resolution 0.39μm
Focal depth ±0.60μm
Pupil diameter φ2.8mm
Real field of View (Eyepiece φ24mm) φ0.24mm
Real field of View (Imaging device 1/2-inch) 0.05×0.06mm
Laser Damage Threshold<sup>*</sup> 0.05J/cm2  at 355nm
Weight 0.53kg
Availability Please contact
i
Near Ultra-violet (NUV) Objective Lens
PAL-50-NUV-A
50× 0.45 15.1mm
6-12 weeks
$5,099.00
Item name MplanApo NUV 50x
Focal length f 4mm
Resolution 0.61μm
Focal depth ±1.4μm
Pupil diameter φ3.6mm
Real field of View (Eyepiece φ24mm) φ0.48mm
Real field of View (Imaging device 1/2-inch) 0.10×0.13mm
Laser Damage Threshold<sup>*</sup> 0.05J/cm2  at 355nm
Weight 0.36kg
Availability Please contact
i
Near Ultra-violet (NUV) Objective Lens
PAL-50-NUV-HR-L
50× 0.65 10mm
2 weeks
$15,862.00
Item name MplanApo NUV HR 50x
Magnification 50×
Numerical aperture (NA) 0.65
Working distance (WD) 10mm
Focal length f 4mm
Resolution 0.42μm
Focal depth ±0.65μm
Pupil diameter φ5.2mm
Real field of View (Eyepiece φ24mm) φ0.48mm
Real field of View (Imaging device 1/2-inch) 0.10×0.13mm
Laser Damage Threshold<sup>*</sup> 0.05J/cm2  at 355nm
Weight 0.51kg
Availability Please contact
i
Near Ultra-violet (NUV) Objective Lens
PAL-100-NUV-A
100× 0.57 11.23mm
6-12 weeks
$6,232.00
Item name MplanApo NUV 100x
Focal length f 2mm
Resolution 0.48μm
Focal depth ±0.80μm
Pupil diameter φ2.3mm
Real field of View (Eyepiece φ24mm) φ0.24mm
Real field of View (Imaging device 1/2-inch) 0.05×0.06mm
Laser Damage Threshold<sup>*</sup> 0.05J/cm2  at 355nm
Weight 0.38kg
Availability Please contact
